DS 2CD1723G1 I(Z)(S)

• 2.54 cm (1/2.8 inch)  Progressive scan CMOS

• 3D DNR (Digital Noise Reduction)
• 1920 × 1080@30fps
• Up to 20 m IR range
• 2.8 mm to 8 mm manual/motorized (with -Z) varifocal l

Camera

Image Sensor: 2.54 cm (1/2.8 inch) Progressive scan CMOS

Min. Illumination: Color: 0.01 Lux @ (F1.2, AGC ON), 0.025 Lux @ (F1.9, AGC ON)

Shutter Speed: 1/3 s to 1/100, 000 s

Slow Shutter: Yes

Day &Night: IR cut filter

Digital Noise Reduction: 3D DNR

WDR: Digital WDR

Angle Adjustment: Pan: 0° to 355°, tilt: 0° to 75°

Lens

Focal length: 2.8 to 8 mm

Aperture: F1.9

Focus: Without -Z model: Manual -Z model: Auto

FOV: Horizontal field of view: 111° to 54.7° Vertical field of view: 57.8° to 30.5° Diagonal field of view: 134° to 63°

Lens Mount: Φ14

IR

IR Range: Up to 20 m

Wavelength: 850 nm

Compression Standard

Video Compression: Main stream: H.265/H.264 Sub-stream: H.265/H.264/MJPEG

H.264: Type Baseline Profile/Main Profile/High Profile

H.264+: Main stream supports

H.265: Type Main Profile

H.265+: Main stream supports

Video Bit Rate: 32 Kbps to 8 Mbps


Max. Resolution: 1920 × 1080

Main Stream: 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720) 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)

Sub-stream: 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)

Image Enhancement: BLC, 3D DNR

Image Setting: Rotate mode, saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser

Region of Interest: 1 fixed region for main stream

Day/Night: Switch Day/Night/Auto/Schedule/Triggered by Alarm In (-S)

Network

Network Storage: Support Micro SD/SDHC/SDXC card (128G), local storage and ANR

Alarm Trigger: Motion detection, video tampering detection, network disconnected, IP address conflict, illegal login, HDD full, HDD error

Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour

General Function: One-key reset, anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark

Firmware Version: 5.5.82

API: ONVIF (PROFILE S, PROFILE G), ISAPI

Simultaneous Live View: Up to 6 channels

User/Host: Up to 32 users 3 levels: Administrator, Operator and User

Client: iVMS-4200, iVMS-4500, iVMS-5200, Hik-Connect

Web Browser: IE8+, Chrome 31.0-44, Firefox 30.0-51, Safari 8.0+

Interface

Audio -S: model: Built-in mic, 1 input (line in), 1 output (line out) Without -S model: Built-in mic

Communication Interface: 1 RJ45 10M/100M self-adaptive Ethernet port

Alarm (-S): 1 alarm input, 1 alarm output

Video Output (Without -Z): 1Vp-p composite output (75 Ω/BNC)

On-board storage: Built-in micro SD/SDHC/SDXC slot, up to 128 GB

Reset Button: Yes

Audio

Environment Noise Filtering: Yes

Audio Sampling Rate: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz

Audio Compression: G.711/G.722.1/G.726/MP2L2/PCM

Audio Bit Rate: 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)

General

Operating Conditions: -30 °C to 45 °C (-22 °F to 113 °F), humidity: 95% or less (non-condensing)

Power Supply: 12 VDC ± 25%, 5.5 mm coaxial power plug PoE (802.3af, class 3)

Power Consumption and Current: -Z model: 12 VDC, 0.8 A, max. 10 W; PoE: (802.3af, 36 V to 57 V), 0.4 A to 0.2 A, max. 12 W Without -Z model: 12 VDC, 0.5 A, max. 6 W; PoE:(802.3af, 36 V to 57 V), 0.3 A to 0.1 A, max. 8 W

Protection Level: IP66, IK10

Material: Bubble: plastic, front cover: plastic, bottom base: metal

Dimensions: Camera: Φ 121 mm × 92 mm (4.8" × 3.6") With package: 150 mm × 150 mm × 141 mm (5.9" × 5.9" × 5.6")

Weight: Camera: Approx. 400 g (0.9 lb.) With package: Approx. 700 g (1.5 lb.)
